Technical data:

Laser working range

—Standard: 30 meters

—In receive mode: 25 meters

—With laser receiver: 5-60 meters

Leveling accuracy: ±0.3mm/m

Self-levelling range: ±3 degrees

Leveling time: <4 seconds

Working temperature: -10℃~40℃

Storage temperature : -20℃~70℃

The maximum use altitude above the reference altitude: 2000 meters

Maximum relative humidity: 90%

Laser class: 2

Laser Type: 500-540 nm, <10 mW

Divergence angle: 50*10 milliradians (full angle)

Shortest pulse time: 1/10000 second

Tripod Connector: 1/4 inch, 5/8 inch

Size: 149*84*142mm

Product Description

Brighter Green Beam

Using German OSRAM technology, the light penetration is strong, and the eye protection is not dazzling. Brighter than the traditional green beam. Both inside and outside are clearly visible.

 Self-Levelling

The self-leveling feature works very well, with a fairly large tilt-handling capability of 3 degrees, and if the level is tilted beyond that, the laser will blink. The laser lines are sharp and bright.

360 laser level

IP54 Protection:

IP54 protection level, with splash water and dustproof functions, can withstand harsh working conditions.

Compact Body Design：

Length: 140mm; Height: 140mm; Width: 80mm. The weight is only 0.85kg. Compact body design makes work easier

Application：
