DAJA A1 UV Laser Marking Machine

DAJA A1 UV Laser Marking Machine

Hign-concerned Chemical: None
Origin: Mainland China
operating syste: EZCAD2
Certification: CE
Certification: ce
Brand Name: DAJA
Model Number: A1
DAJA Model: A1
Laser Power: 3w/5w
Laser wavelength: 355nm

DAJA A1 UV Laser Marking Machine

Hign-concerned Chemical: None
Origin: Mainland China
operating syste: EZCAD2
Certification: CE
Certification: ce
Brand Name: DAJA
Model Number: A1
DAJA Model: A1
Laser Power: 3w/5w
Laser wavelength: 355nm
Whole Machine Power: 600W
Engraving area: 150mm*150mm
operating system: EZCAD2.0/LIGHTBURN

About plugs and voltage

We will provide matching plugs and voltages according to the power standards of your country. If you have special needs, you can contact us or indicate it in the order. Thank you for your support and trust.

Product Information

Engravable materials: all metals such as gold, silver, aluminum, jewelry, stainless steel, oxidized metals, and all non-metals such as glass, ceramics, leather, and plastics. It can also engrave various circular and cylindrical objects with the help of rotary attachments. One machine can meet various engraving needs.
Plug support:EU/US/UK/AU（We will send matching plugs according to your country or region. If you have special requirements, you could contact us to change it.）
Whole machine power:600W
Spot circularity:>90°
Engraving area: The default size is 150*150mm (if you need to change other field lenses, you could contact us)
Product weight: 22kg
Machine size: 58cm*33cm*50cm
Support languages:English/Portuguese/Spanish/Russian/Korean/Japanese/Arabic/Vietnamese/Thai/French/German/Türkive/ Chinese
Pulse width: ≤12ns@30kHz
Puise Repetioon Rate Range: 10kHz to 150kHz(Optionssingle shot to 200kHz)
Average Power: >3W@30kHz
Average PowerStbity: <+3%over 24 hours
Single pulse stability: <3%rms
Bear Dovergence Fiull Angle: <2mrad
1/e2 Beam Diameter: 0.7mm
Exit spot diameter: 0.7mm
Pointing stability: <50urad
Laser wavelength: 355nm
Spot mode: TEM00(M2<1.2)
Repetition frequency: 10kHzto150kHz
Polarization Direcsion Horizontal
Polarization Ralio 100:01:00
Cooling system: air cooling systemSupported format: PLT/DXF/BMP etc.
Support system: Win7/Win10/XP
