FOXWELL SD201 12V Car Smoke Leak EVAP

• Hign-concerned Chemical: None
• Brand Name: FOXWELL
• Origin: Mainland China
• Feature: Built in air pump
• Support Vehicle: Motorcycle, Passenger Vehicle
• Exhaust Gas Analyzer Tool: Check the tightness of the pipeline
• FOXWELL: 100% Original
• FOXWELL SD201 Warranty: 3 Year,3 Year
• Motorcycle Gas Diagnostic Tool: EVAP Leakage detect
• Car Oil Pipe Diagnostic Tool: fuel pipe,air intake system and cooling tank
• Auto Gas Diagnostic Tool: Autos Pipe Systems Smoke Leakage Detector
• Support System 1: Car Sealing Test;Various Pipe Fittings Test
• Support System 2: Fuel Tank System Test
• Support System 3: Intake System Test;Exhaust System Test
• Smoke output value: 6l/min

Buy-this-product-on-Aliexpress

Notice any weird smells or fluids? Is your ride acting all wonky? Dashboard lighting up with CEL, BRAKE, AC, EVAP, STEERING, COOLANT, and more? Foxwell SD201 is capable of promptly detecting and addressing leakage issues in various areas such as the engine, e-xhaust system, or vacuum lines. Preventing leak from escalating and leading to substantial repair costs when taken to a repair shop.

Why You Need a Smoke Leak Detector？

For example:

1. The rupture of the vacuum hose will cause the mixture to be too thick, the idle speed will increase, the hot car will not start well, the engine will surge during acceleration, the fuel consumption will increase significantly, and the exhaust pipe will emit black smoke.
2. Blocking will cause the idle speed to drift, and the idle speed is easy to stall.
3. Air leakage in the vacuum tube will cause the engine to run weakly

Resolve Leaks Promptly

Contributes to safer driving conditions

All in One, Meet Your Need!

The C-shaped embedded structure design has a stronger sense of hierarchy, making it not only a car repair tool, but also a handicraft.

A brand new smoke generation device with patented technology. Compared with peer products, at the same smoke concentration, it consumes less electricity and less e-liquid.

With the support of frequency conversion technology, even under high temperature protection, it can meet daily testing needs without the need to stop and wait. 10 minute work cycle

Compared to the 5-minute working cycle of peers, a longer testing time means it can meet the testing needs of more systems, such as the cab, large volume piping systems, water tanks, and so on.

Buy-this-product-on-Aliexpress

Compatibility with most vehicles and systems, EVAP service kit and sealing plugs

The Foxwell SD201 automotive smoke leak detector is suitable for detecting pipeline system leaks on cars, motorcycles, snowmobiles, beach bikes, light trucks, heavy-duty trucks, and speedboats.

Product Features

Smoke leak detector, due to the characteristics of smoke, can perform leak detection on the entire pipeline, with visual operation, all-round, no dead corners, and no missing leakage points.

Short smoke output time: Output a large amount of smoke within 10 seconds, greatly reducing diagnostic time and improving work efficiency.

Simple and practical: With easy-to-use features and hook design, the conical adapter and airbag adapter can adapt to most air intakes.

Overheat and antifreeze protection: The smoke detector is equipped with the latest intelligent protection devices. When the temperature of the equipment exceeds 75 degrees Celsius, the power protection device will intelligently start and shut down to ensure the safety of the operator and equipment. If the device operates continuously for more than 15 minutes, it will be protected from overheating for a protection time greater than 10 minutes. This device is also suitable for low-temperature operation. Only car batteries with a full capacity of 12V are supported.

Integrated Air Pump, Highly Flexible

Discover potential leaks, repair them promptly – forever your car’s doctor! Built-in pump for easy use and portability. Stress output 0.8-1.2 bar suits most car systems. Compared to others, SD201 offers better value—spend less, pinpoint leaks faster!

Precise Check for EVAP

How to Test It?

1. Inject 10ml-20ml of test oil into the smoke leak detector, filling 20ML of test fluid, under standard working conditions, can be used continuously for about 10 minutes; (about Smoke Oil: advise use the Baby oil)
2. Open the pipe that needs to be connected with the leak detector.
3. Install the airbag adapter into the sealed pipe and connect the device to the smoke conduit.
4. Connect the leak detector to the DC12V battery and the device will start working. NOTE: red clamp tp positive(+), and black clamp to negative(-)
5. The pipe will be filled with smoke and the leakage point will be checked.
6. Test the leaking pipeline, under the premise of sealing accurately, generally about 1 minute can be filled with smoke, if there is a leak, within 3 minutes, you can observe the results.

Variable Frequency operation

It Adopts advanced variable frequency operation technology .

FOXWELL SD201 Packing List
