HDP800 series pressure transmitter

• Model Number: HDP800
• Max Measuring Range: 400 Bar & Above
• Origin: Mainland China
• Certification: CE
• Output signal: 4-20ma,1-5v,0-10v,RS485,etc
• Power supply: 12-28VDC
• Measuring medium: oil,water,gas
• Pressure range: 0~100MPa
• Shell Protection: IP65
• Accuracy: 0.1%F.S,0.2%F.S
• Long-term stability: ±0.2%F.S/y
• Linearity: 0.03%
• Overload pressure: 200%F.S
• Load capacity: ≤500Ω
• Response time: ≤50MS

HDP800 series pressure transmitter pressure sensitive core adopts high performance silicon piezoresistive pressure filling core. The internal ASIC converts the sensor millivolt signal into standard voltage, current or frequency signal, which can be directly connected with computer interface card, control instrument, intelligent instrument or PLC. Current output mode can be used for distance transmission. It has small volume, light weight, all stainless steel sealing structure and can work in corrosive environment. The product is easy to install and has high anti-vibration and anti-impact performance. It is widely used in process control, aviation, aerospace, automobile, medical equipment, HVAC and other fields.

Buy-this-product-on-Aliexpress

Product details

Our services

1.We guarantee you the lower pricing from us compared with your any competitive prices from others in volume.
2.We can guarantee you any quality issue from us will be refund you immediately or replace with new & qualified products.
3.OEM, Accept lower quantity trial order
4.Fast delivery. 24 hours With Discount Courier, Air shipment
5.Contains a variety of industrial control products such as signal isolators, pressure and liquid level sensors, temperature, current, voltage, frequency and other transmitters.
All products are in stock (except for special customization).
6.We can support you 24Hours online service via Alibaba, email, skype, what’sapp, facebook etc.
7.Long term warranty. Pressure and level transmitters are 2 years. The others in our shop are with 5 years warranty!!

Applications

It is widely used in process control, aviation, aerospace, automobile, medical equipment, HVAC and other fields.

Company information

Huadian specializes in High-tech R&D, focuses on selfdeveloping, manufacturing and selling of measurement and control products for pressure, temperature, liquid level and flow.
