Name: JRJ300-D-1/ JRJ300-SH Lab High Shear Blender Cosmetic Homogenizer Emulsion Mixer
SKU: 3256802038826540

JRJ300-D-1/ JRJ300-SH Lab High Shear Blender Cosmetic Homogenizer Emulsion Mixer

JRJ300-D-1/ JRJ300-SH Lab High Shear Blender Cosmetic Homogenizer Emulsion Mixer

Model Number: JRJ300-D-1/ JRJ300-SH
Origin: Mainland China
Certification: none
Classification: Laboratory Thermostatic Devices
Stators Size: 50mm/20mm/5mm
Continuously working time: 3-10 minutes
Max mixing volume: 40L

JRJ300-D-1/ JRJ300-SH Lab High Shear Blender Cosmetic Homogenizer Emulsion Mixer

Model Number: JRJ300-D-1/ JRJ300-SH
Origin: Mainland China
Certification: none
Classification: Laboratory Thermostatic Devices
Stators Size: 50mm/20mm/5mm
Continuously working time: 3-10 minutes
Max mixing volume: 40L
Max Viscosity: 12000Mpas
Max Speed: 11000rpm
Torque: 34.1N.cm
Power: 300w

Product Description:

The laboratory high-speed shearing dispersing emulsifier is driven by a compact series-excited miniature high-speed motor, which is suitable for the stirring and mixing of low to medium and high viscosity liquids in the laboratory or pilot plant, and the shearing and emulsification of crushed particles in the liquid medium . The machine is composed of a drive motor with a high-density die-cast aluminum alloy body, a high-quality stainless steel refined shearing emulsification working head and a speed controller.

Buy-this-product-on-Aliexpress

Features:

The running state controller with the step less speed governor, JRJ300-SH use the touch type structure, the speed adjustment is convenient,and the data is correct;

The drive motor is high-speed and with large output power, Safety design;

The working head with high quality stainless steel material ,corrosion resistant;

The working head is connected with the drive motor by a coupling, which is easy and flexible to disassemble.

Our Models Parameters are as below:

Model no.	JRJ300-D-1	JRJ300-SH(Digital display)
Rotary Speed	200-11000R/MIN	200-11000R/MIN
Capacity	40L	40L
Input Power	510W	510W
Output Power	300W	300W
Exterior Dimension	250650720mm	250650720mm
Tated Torque	34.1N.cm	34.1N.cm
Working Diamter	70mm	70mm
Stator type	5mm²，20mm²，50mm²	5mm²，20mm²，50mm²
Voltage	AC 220V 50HZ	AC 220V 50HZ

Buy-this-product-on-Aliexpress

Matters Needing Attention:
1. The mixing head must be completely immersed in the liquid before starting. Otherwise, the rotor may get stuck due to thermal expansion.
2. The homogenizer runs intermittently for no more than five minutes at a time. If the treatment capacity is small, the time can be shortened.
