SMART SENSOR AR991 Grain Moisture Meter

Smart Sensor Digital Moisture Meter Grain Moisture Meter Use For Corn,Wheat,Rice,Bean,Wheat Flour fodder rapeseed seed

 1. All products with original packaging box, so that can protect the products well on the shipping way avoid damage.

  2. The product does not contain the battery because of the limitation of the airline company.
 3. Warranty: All units are with Retail box. and we offer Long warranty period of 2 years,in two years will repair for free.
 4. Shipping Way: if you need it faster, you can choose Aliexpress standard shipping,also have China post airmail !

Smart  Sensor Moisture meters are used to measure the percentage of water in a given substance. This information can be used to determine if the material is ready for use, unexpectedly wet or dry, or otherwise in need of further inspection. Grain Can Be  Measured: rapeseed, sesame, soybean meal, cotton, soybean, peanut,barley, rice, sorghum, watermelon seed, paddy, wheat, maize, fodder

Specifications: Grain Can Be Measured:		rapeseed, sesame, soybean  meal, cotton, soybean, peanut,  barley,  rice,  sorghum, watermelon  seed,  paddy, wheat,  maize, fodder
Principle of Measurement		Resistance Method
Accuracy		0.1 / 01%
Backlight Display		yes
Deviation Adjustment		yes
Voice-over		yes
Resistance Alarm  Setting		Pre-set 10 ( Adjustable )
Memory Function		yes
Power		4 x 1.5V AA  Battery (not include)
Product Net Weight		254g
Product Size		80 x 43 x 425mm
Packing		Gift Box
Standard Quantity  Per Carton		40
Packing contents		1pc Moisture meter 1pc user manual 1pc gift box

All varieties codes and moisture measurement range:
Variety	Paddy	Wheat	Corn	Barley	Rice
Code	0	P1	P2	P3	P4
Range	11~55	11~55	11.5~55	11~50	11~50
Variety	Sorghum	Feed	Rapeseed	Seed Melon	Sesame
Code	P5	P6	P7	P8	P9
Range	11~50	11~50	7.5 ~44	50	7.5 ~44
Variety	P10	P11	P12	P13
Code	P10	P11	P12	P13
Range	7.5~44	10~50	10~50	7.5~44

User’s guide

1. Display:  English characters with a low-power digital LCD backlight. Low-power backlight Description: Backlight will be off when no measurment, and the backlight will be on when measuring

2. Voice-Over:  Instrument setting, testing, inspection, all accopmpanies by voice reminder. Language: English voice-over includeds the following 4 modes: d1= The moiseture content readings,/d2= High moisture content /d3= Voice-over off, /d4= bip-sound

3. Mode change:  Oven control calibration method, user can adjust -3% to + 5%. Click the ” Adjust” button to adjust the loop gain value, first addition and then subtraction. after amendment, press the ” ON/OFF” button for  2 seconds, The setting will be saved when shuting down.

4.Speed modeAlarm setting:  Adjustable, factory default alarm is 10%

5. Memory function setting:  If the battery was removed, the setting content will never disappear, To save the setting content, press the ” ON/OFF” button for? 2 seconds. The setting will be saved when shutting down.

6. Lower power reminder:  When battery power is low, the battery symbol on the LCD display will be blank, then user should replace the battery.

7. Measuring principle and sampling method:  Resistance method and continuous sampling.

8. The upper and lower limits of moisture measurement:  Insert the meter to the measured of the meter, the meter can measure the moisture of the measured object, when the measured?object  was too dry below the  minimum measuring range, the meter will display” LO” for no result. When the test was too wet exceeded the?  maximum measuring??range, the meter can only  display ” Limit”

9.Single measurement:  When the probe of the meter is inserted in to the measured object, and the moisture content was within the measuring range, the LCD display will show the moisture reading for few seconds, and voice-over will report the reading immediately.
