SMART SENSOR AS926 Rotational Speed Meter
- Type: Tachometer
- Model Number: AS926
- Brand Name: SMART SENSOR
- Certification: CE,FCC
- Origin: Mainland China
- LCD Display:: 5 digitas and Large LCD display
- Measuement Range: 100~30000RPM
- Rotating Speed Resolution: 0.1RPM (2.5~999.9RPM) 1RPM (Over 1000RPM)
- Measuring Distance: 50mm~400mm
- Accuracy: ±(0.05% 1 digits )
- Sampling Time: 0.8 sec(Over 60RPM)
- Test range select:: Automatic range
- Tachometer: digital Tachometer
- Digital photo Tachometer: Laser Tachometer
- Rotational Speed Meter: Non-contact Measuring Instrument
SMART SENSOR Digital photo Tachometer AS926 100~30000RPM
1. All products with original packaging box,so that can protect the products well on the shipping way avoid damage.
2. The product does not contain the batterybecause of the limitation of the airline company.
3. Warranty:All units are with Retail box. and we offer Long warranty period of 2 years,in two years will repair for free.
4. Shipping Way:if you need it faster, you can choose Aliexpress standard shipping,also have China post airmail !
SMART SENSOR tachometer (RPM gauge) is an instrument measuring the rotation speed of a shaft or disk, as in a motor or other machine. The device usually displays the revolutions per minute (RPM) on a digital displays.
Applying the MCU, photoelectricity and laser semiconductor technology, perform measurement of rotating speed without contact
1.Applying the MCU, photoelectricity and laser semiconductor technology, perform measurement of rotating speed without contact
2. Wide measuring range and high resolution
3. Large LCD display
4. Automatically store the MAX,Min and LAST value
5. Low battery indication
6. ELEGANT and easy to use.
7. Solid structure built with durable electronic elements and light ABS plastic house
| LCD Display | 5 digitas and Large LCD display |
| Measuement Range | 100~30000RPM |
| Rotating Speed Resolution | 0.1RPM (2.5~999.9RPM) 1RPM (Over 1000RPM) |
| Measuring Distance | 50mm~400mm |
| Accuracy | ±(0.05%+1 digits ) |
| Sampling Time | 0.8 sec(Over 60RPM) |
| Test range select: | Automatic range |
| Max / Min Measuring | V |
| Data Storage | V |
| Memories Clear | V |
| Battery Indication | V |
| Power Consumption: | About 50mA |
| Power | 3*1.5V AAA Battery ( not include due to air limit) |
| Product Net Weight | 91g |
| Product Size | 134.5 x 50 x 26mm |
| Packing | Blister package |
| 1. Apply a reflection mark to the object being measured, Press” TEST button key and align the laser beamwith the measure target 2. Release the TEST button when the display is stable, The result will display on the LC, which will be stored automatically 3.Press TEST button again, the unit will be turned off. 4. This unit have the auto turn off function to save the battery lift, when power on, if there is not any further operation, the unit will turn off in 609 seconds |
|
