TwoTrees TTC450 CNC Router with Rotary 4th Axis – Laser Engraving & Cutting for Wood, MDF, PVC, Metal

TwoTrees TTC450 CNC Router with Rotary 4th Axis – Laser Engraving & Cutting for Wood, MDF, PVC, Metal

TwoTrees TTC450 Rotary 4th Axis CNC Wood Engraving Machine Laser Engraver Cnc Router For MDF PVC Epoxy Metal Carving Cutting



The motherboard adopts ESP32 highly integrated chip with low power consumption, high stability and reliability, ultra-high processing speed and large memory, supports offline controllers, supports four axes, and supports PWM laser signals.

Brand： TWO TREES

Model： TTC-450

Engraving area: 460mmX460mmX80mm

Power adapter power：120W, 5A, 24V

Spindle parameters ： 24V 5A, 775 motor 8000RPM

Tool setting： Software Control / manual / Tool setting instrument.

Control Board Compatibility： GRBL

Engraving speed MAX :   MAX800mm/min

Limit switch: X, Y, Z three-axis double limit + ESTOP

Engraving accuracy:   0.01mm

Stepper driver:   A4988 1.3A (other drivers can be connected to the motherboard)

Linear transmission mode: Built-in POM wheel

Stepping motor   NEMA 23 (2 phases, 1.5A) torque 20mN. m

Transmission type ： T8 screw pitch 2mm lead 4mm screw / Y-axis Double Y-axis with built-in rollers

Emergency stop switch Yes

Harness management: XY energy chain

Machine weight kg: 19.2kg

Shipping weight kg: 20kg



CAM software

control: Candle

Programming: CarvecoMaker, Artcam, Easel

Operating system Windows XP/7/8/10/11, MAC OS



Engraving materialsEngraving and cutting MDF, PVC, acrylic, solid wood, particle board, plywood, organic board, epoxy resin, nylon, PCB, aluminum, copper, carbon fiber board, etc.
